Independent 4x4 Switching
Route any of four 4K sources to any of four HDMI displays at the same time, giving each zone its own content.
System integrators, IT managers, and audio visual equipment suppliers choose the MX44HAS2 when they need dependable 4x4 HDMI routing with 18 Gbps bandwidth, Dolby Vision, HDR10, and HDCP 2.2. Audio visual suppliers also value the built-in scaler output, EDID management, S/PDIF audio extraction, and flexible control options such as IP, RS-232, IR, and front-panel buttons.
Product Overview
The MX44HAS2 gives you four HDMI inputs and four HDMI outputs, so any source — laptop, media player, camera, or computer — can be sent independently to any display in the system.
Designed for professional AV installations, the matrix supports 4K @60Hz 4:4:4 video, HDR10 and Dolby Vision, HDCP 2.2, and 18 Gbps bandwidth. It also includes audio breakout on each output, a scaler output, and EDID management for cleaner system setup and reliable signal handshakes.
Features
Signal integrity, flexible control, and easy commissioning make the MX44HAS2 a practical choice for multi-screen environments.
Route any of four 4K sources to any of four HDMI displays at the same time, giving each zone its own content.
Supports 4K @60Hz YUV 4:4:4, 3D, HDR10, and Dolby Vision with HDMI 2.0a compliance and 18 Gbps bandwidth.
The scaler output helps source resolutions and display capabilities work together more smoothly.
S/PDIF coaxial audio extraction is available for each HDMI output, making it easy to feed amplifiers, soundbars, or receivers.
Learn EDID from connected displays or choose from pre-programmed EDID settings for more predictable handshakes.
Use front-panel push buttons, IR remote, RS-232, IP/Web GUI, or USB control to match the needs of the installation.
Specifications
Fast facts from the official GreatProAV product information for the MX44HAS2.
| Type | HDMI Matrix 4x4 — 4 HDMI inputs to 4 HDMI outputs |
|---|---|
| Model | MX44HAS2 |
| Bandwidth | 18 Gbps |
| Video Support | 4K @60Hz 4:4:4, 3D, HDR10, Dolby Vision, color space 444 |
| HDMI Compliance | HDMI 2.0 / HDMI 2.0a, HDCP 2.2 |
| Color Depth | 4K @60Hz YUV 4:4:4 8-bit; HDR at 4K @60Hz YUV 4:2:0 10-bit |
| Audio Support | DTS-HD, Dolby TrueHD, 7.1ch digital audio, and all other standard HDMI audio formats |
| Audio Breakout | S/PDIF coaxial audio extraction for each HDMI output |
| EDID | EDID learning from connected displays plus pre-programmed EDID settings |
| Control Interfaces | Front-panel buttons, IR remote, RS-232, IP/Web GUI, USB |
| Enclosure | Metal, surface-mountable, with ESD protection |
| Certifications | FCC, CE, RoHS |
| Additional | Scaler output, signal retiming, plug-and-play operation, no driver required |
Keep adjacent product options together for a faster catalog comparison.
High-performance HDMI 2.1 multiviewer supporting 16×1 input and 8K60 output. Ideal for video wall controller, HDMI Matrix, and HDMI Splitter deployments by audiovisual professional
View product
Transmit 4K@60Hz up to 70m with ARC and IR using this HDBaseT extender. Ideal for audio visual suppliers and video conferencing equipment supplier needs.
View product
Engineered for ProAV, this 4x1 hdmi multiviewer delivers 4K60 performance with PiP/PoP modes. A reliable video processor for seamless multi-source monitoring.
View productit connects up to four hdmi sources and lets you route any source independently to any of four hdmi displays — useful for boardrooms, classrooms, houses of worship, and multi-screen av systems.
the matrix supports up to 4k @60hz 4:4:4, 3d, hdr10, and dolby vision, with hdmi 2.0/2.0a, hdcp 2.2, and 18 gbps bandwidth.
yes. each hdmi output supports s/pdif coaxial audio extraction, which makes it convenient to connect downstream amplifiers, soundbars, or other audio systems.
control options include front-panel push buttons, ir remote, rs-232, ip/web gui, and usb. the unit also includes signal retiming and requires no driver for basic plug-and-play use.
the mx44has2 can learn edid from connected displays or use pre-programmed edid settings, helping to reduce handshake issues and improve source-to-display compatibility.
use the official greatproav product page to review current details, or contact the greatproav team through the contact us page for pricing, availability, and project assistance.
